Item
|
Descriptions
|
Item
|
Descriptions
|
|
|
인터페이스 수
|
8-Port 10/100/1000Base-T Combo RJ-45
|
기능
|
Port Mirroring 기능 지원
|
|
|
28-Slot 1000Base-X SFP
|
IEEE 802.1x
|
|
|
표준방식
|
IEEE 802.1q, IEEE 802.1d, IEEE 802.1p
|
Link aggregation (IEEE 802.3ad), 8 Groups
|
|
|
IEEE 802.3, IEEE 802.3u, IEEE 802.3x
|
STP(IEEE 802.1D), RSTP(IEEE 802.1w), MSTP(IEEE 802.1s)
|
|
|
Console Port
|
RJ-45 to RS-232
|
|
|
Packet Priority (IEEE 802.1p)
|
|
|
Processor
|
MIPS32 700MHz
|
|
|
Automatic Loop Detection and Isolation
(RLPP/RLDP)
|
|
|
Flash
|
16MB
|
|
|
Memory
|
256MB DDR3 SDRAM
|
|
|
IEEE 1588v2
|
|
|
Switching Capacity
|
56Gbps
|
|
|
IEEE 802.3az Energy Efficient Ethernet (EEE)
|
|
|
Bridge Function
|
Filtering, Forwarding, Learning
|
|
|
L2/L3/L4 기반 ACL (DMAC, SMAC, Ether-Type)
|
|
|
Switching 방식
|
Store and Forward
|
|
|
IGMP v1/v2/v3, MLD v1/v2 Snooping 지원
|
|
|
Flow Control 방식
|
IEEE 802.3x and Back-Pressure Flow Control
|
|
|
Auto MDI / MDIX 자동감지기능 지원
|
|
|
MAC Address
|
16K
|
|
|
Broadcast Storm Control
|
|
|
VLAN Functions
|
Tag-base VLAN (IEEE 802.1Q)
|
|
|
BPDU Flood /Drop기능제공(Bridge Protocol
Data Unit)
|
|
|
Port-base VLAN, Port and protocol based
VLAN
|
|
|
정격전원
|
AC90~250V, 50Hz/60Hz
|
|
|
Management
|
CLI, Telnet, Web based Management
|
|
|
SNMPv1/v2c/v3, MIB I/II
|
소비전력
|
Max. 33 W
|
|
|
Rate Limit Control
|
각 포트별 16Kbps 단위 대역폭 속도 조절가능
|
|
|
크기
|
440(W) x 290(D) x 44(H) mm
|
|
|
MAC Filtering
|
접근제한 MAC Address 입력하여 관리
|
|
|
동작온도
|
0°C ~ 70°C
|
|
|
QoS
|
8 Physical Queues per Port
|
|
|
Strict Priority(SP) and Weighted Fair Queue(WFQ), Weighted Round Robin (WRR) Packet Scheduling
|
보관온도
|
-40°C ~ 80°C
|
|
|
습도
|
10% ~ 90%(non Condensing)
|
|
|
QoS remarking for 802.1p and DSCP
(includes IPv4/IPv6)
|
|
|
LED
|
Power, Run, Link / ACT
|
|
