| Camera Module |
| Image Sensor |
1/2.8″ progressive scan CMOS |
| Mini. Illumination |
Color：0.01Lux @ (F1.65，AGC ON) B/W：0.002Lux @ (F1.65，AGC ON)
0 Lux with IR |
| Image setting |
Flip, Mirror, Saturation, Brightness, Contrast, Sharpn ess, AGC, and AWB adjusted by client software / bro wser |
| Shutter Speed |
1/1 s – 1/100,000 s |
| White Balance |
Auto / Manual / Indoor / Outdoor |
| Gain |
Auto / Manual |
| Day & Night |
IR Cut filter |
| 3D DNR |
Auto / Manual |
| Image Enhancement |
BLC, HLC, WDR(120 dB) |
| Defog |
Electronic |
| EIS |
YES |
| Picture overlay |
Logo picture could be overlaid on video with
128×128pixels, 24bits jpg format |
| Lens |
| Focus length |
f=4.8-120mm lens, 25x optical |
| Zoom Speed |
Approx. 3.6s (optical zoom, wide-tele) |
| Field of View |
Horizontal:55° to 2.4°(wide-tele) Vertical: 33° to 1.4°(wide-tele) Diagonal: 61.5° to 2.8°(wide-tele) |
| Working distance |
wide: 1.0m ~ INF; tele: 1.5m ~ INF |
| Aperture Range |
F1.65 ~ F3.8 (wide-tele) |
| PTZ |
| Pan Range |
360°endless |
| Pan speed |
Configurable, from 0.4~80°/s
Max Preset speed: 80°/s |
| Tilt Range |
From -5° to 90° |
| Tilt Speed |
Configurable, from 0.4°~ 80°/s, Max Preset speed: 80°/s |
| Proportional Zoom |
Yes |
| Preset |
360 |
| Cruise |
8 cruises, up to 16 presets for each cruises |
| Track |
4 tracks, record time over 3 minutes for each track |
| Power off memory |
Support |
| Action mode |
Preset / Cruise / Track / Auto Scan / Random Scan |
| PTZ Position Display |
Support |
| Schedule Task |
Preset / Cruise / Track / Auto Scan / Random Scan / Dome reboot |
| IR |
| IR Distance |
100m |
| Smart IR |
Yes |
| Network |
| Max Resolution |
2560×1440 |
| Main stream |
2560×1440, 2048x1536, 1920×1080 ,1280x960,
1280×720 25/30fps |
| Sub stream |
25fps (704×576 , 640x480, 352×288)
30fps (704×480, 640x480, 352×240) |
| Third Stream |
25fps (1920x1080, 1280x960, 1280x720, 704×576
, 640x480, 352×288)
30fps (1920x1080, 1280x960, 1280x720, 704×480,
640x480, 352×240) |
| Video compression |
Smart H.264+ / H.264 / MJPEG |
| Audio compression |
G.711 A / U |
| Audio Enhancement |
NO |
| Protocols |
HTTP, HTTPS, IPv4/IPv6, 802.1x, QoS, FTP, SMTP, U PnP, SNMP,DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/ IP, UDP, IGMP, ICMP,DHCP, PPPoE |
| Simultaneous live view |
Up to 6 channels |
| User / Host |
Up to 16 users, 3 levels: Administrator, Advanced Us er and Normal User |
| Security Measures |
User authentication (ID and PW), Host authenticatio n (MAC address)
HTTPS encryption, IEEE802.1x port-based network access control; IP address filtering |
| Smart Features |
| Basic event |
Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, SD full, S D error) |
| Face recognize |
Default off, max 15 human faces per second. |
| Face compare |
Default off |
| Smart Detection |
Intrusion detection, Line crossing detection, Region entrance detection, Region exiting detection, Unatte nded baggage detection, Object removal detection, Scene change detection, Support alarm triggering b y human or vehicle, filtering flag/animal. |
| Smart Tracking |
Manual Tracking, Auto Tracking
(human or vehicle by software setting) |
| System Integration |
| Alarm Linkage |
Alarm actions, such as Preset, Cruise, Track, Memor y Card Video Record, Trigger Recording, Notify Surv eillance Center, Upload to FTP/Memory Card, Send E mail, etc. |
| Network Interface |
1 RJ45 10M/100M Adaptive Ethernet
(Support PoE 802.3.at) |
| Storage |
SD card slot inside, support micro SD/SDHC/SDXC, up to 256G |
| Web Browser |
IE8-11,Chrome41.0-44, irefox30.0-51,Safari8.0-11 |
| System Integration |
| Power |
DC12V or PoE+ (802.3.at, class 3),
(Max 22W, include IR on, Heater on, Fan working) |
| Working condition |
-30°C ~ 55°C (-22°F ~ 131°F),
90%RH less (non-condensing), Cold start at – 20°C |
| Storage condition |
-40°C ~ 65°C ; ≤ 95% RH |
| Protection |
IP66 Level, 4000V Lightning Protection,
Surge Protection and Voltage Transient Protection |
| Material |
Aluminum Alloy ; Plastic +Glass Fiber 10% |
| Dimensions |
Φ 173mm × 247mm ( 6.8′ Φ × 9.7′) |
| Weight |
Approx. 2.1 Kg (13.22 lb.) |
| Certification |
KC, CE, FCC |
