Interface
|
24-Slot 100Mbps/1Gbps SFP
2-Slot 1Gbps/2.5Gbps SFP
1-Port 10/100/1000Base-T
|
|
Console Port
|
RJ-45 to RS-232
|
|
Processor
|
MIPS 416MHz, 32-bit CPU
|
|
Flash
|
16MB
|
|
Memory
|
128MB DDR2 SDRAM
|
|
Backplane
|
90Gbps
|
|
Port Control
|
Port Speed/Duplex Mode/Flow Control
Port Frame Size (Jumbo Frame Max. 9.6KB)
Port State (Administrative Status)
Port Status (Link Monitoring)
Port Statistics (MIB Counters)
Port Cable Diagnostics
SFP Detection
|
|
QoS
|
Traffic Classes (4 or 8 Active Priorities)
Port Default Priority
Input Priority Mapping
QoS Control List (QCL)
Storm Control for Unicast, Multicast, Broadcast
Port/Queue Egress Shaper
DiffServ (RFC2474) Remarking
Tag Remarking
|
|
Features
|
IEEE 802.1D Bridge (Auto MAC Address Learning/Aging, MAC Addresses-Static)
IEEE 802.1Q VLAN
MAC, Protocol, IP Subnet based VLAN
VLAN Trunking
Private VLANs / Port Isolation
IEEE 802.1d STP, IEEE 802.1w RSTP
IEEE 802.3ad Link Aggregation
IGMPv2, IGMPv3 Snooping
MLDv1, MLDv2 Snooping
ARP Inspection
Port Mirroring, Flow Mirroring
|
|
Security
|
IEEE 802.1X (Port-based 802.1X, Single 802.1X, Multiple 802.1X)
MAC based Authentication
RADIUS Accounting
MAC Address learning control (Auto, Disable, Secure)
Static MAC Table
Web & CLI Authentication
ACLs for Filtering/Policing/Port Copy
Networks Access Server (NAS)
|
|
Management
|
DHCPv4 Client
Web-based Management
CLI, Telnet
SNTP (Simple Networks Time Protocol)
HTTPS, SSHv2
System Syslog
Software Upload via Web
SNMP v1/v2c/v3 Agent
SNMP Trap Group
RMON (Group 1, 2, 3, 9)
RMON Alarm and Event (CLI, Web)
IEEE 802.1ab Link Layer Discovery Protocol - LLDP
Configuration Download/Upload
|
|
Power
|
AC90~250V, 50Hz/60Hz
Power redundancy
|
|
Power Consumption
|
Max. 35W
|
|
Size
|
440(W) * 247(D) * 44(H) mm
|
|
Operating Temperature
|
-20°C ~ 80°C
|
|
Storage Temperature
|
-40°C ~ 90°C
|
|
Humidity
|
10% ~ 90%(non Condensing)
|
|
LED
|
Power1, Power2, Link/Act, Speed
|
