| Internal Storage |
8 x SATA HDD |
| System |
Embedded Linux |
| IP Camera |
Ch |
36 Ch |
| Protocol |
FOCUS, ONVIF |
| Registration |
Auto, Drag and Drop, Manual |
| Display |
Speed |
1080 fps |
| Screen Mode |
1, 4, 9, 16 , 25, 36 |
| Video Input |
IP Camera (up to 4K UHD) |
| Video Output |
Monitor Out |
Composite & VGA & HDMI |
| HDMI |
1280 × 1024, 1920 × 1080, 2560 × 1440, 2560 × 1600, 3840 × 2160 (optional) |
| Recording Speed |
CIF |
1080 fps |
| 960H |
1080 fps |
| HD |
1080 fps |
| Full HD |
1080 fps |
| Recording Resolution |
Mainstream (up to 4K) & substream |
| Recording Mode |
continuous, motion, sensor, continuous + motion, continuous+sensor, motion+sensor recording |
| Schedule recording, pre&post alarm recording, emergency recording |
| Play&Search |
Speed |
x1, x2, x4, x8, x16, x32, x64, x99 |
| Ch & Resolution |
1 & 4 : Mainstream |
| 9, 16 , 25 & 36 : Substream |
| Function |
Intelli-SearCh by Time Bar, Calendar (Date & Time) and Event SearCh |
| External Storage |
2EA e-SATA |
| Audio Input/Output |
1 Ch / 1 Ch |
| Alarm Input/Sensor Output |
8 Ch / 4 Ch |
| P/T/Z Control |
ONVIF |
| Network |
Interface |
2EA Gigabit Ethernet (RJ45) - Static IP, DHCP & DDNS |
| IPV4, TCP/IP, DHCP, HTTP, RTSP, STMP, FTP, Zero Configuration, NTP, DDNS |
| Bandwidth |
up to 200 Mbps |
| Network Function |
1) Dual stream (Local storage & network transmission) |
| 2) Dual recording (real-time screen / search) |
| 3) Real-time monitoring, remote playback and file backup(Triplex-on-Remote) |
| 4) NTP server time synchronization ("pool.ntp.org") |
| 5) Email sending, remote system reboot, remote PTZ |
| 6) P2P function – no network port forwarding required |
| Remote Management |
Software |
CMS & MMS (MV3000 |
| Web (IE) |
Live monitoring, search & system setting |
| Backup |
Local backup using 2 USB devices, network backup using CMS, FTP server upload backup |
| System recovery after power failure |
Auto-Reboot and Journaling File System |
| Advanced function |
1) Support upgrade through USB and CMS network |
| 2) Bring and put out the setting values |
| 3) Specify the recording period with simple settings |
| 4) HDD SMART smart information (model, capacity, bad sectors, temperature, period of use) |
| 5) Warning alarm when system internal temperature rises |
| 6) Easy installation and multi-language support, help function |
| 7) Digital zoom available |
| 8) Smart search |
| POS |
Text-in Based (USB to Serial support, TCP/IP Network) |
| System Operation |
IR remote control, USB mouse |
| Operating temperature/humidity |
5 ~ 40 ℃ |
| Humidity 20 ~ 90% |
| Power |
AC 100 ~ 240V, 50/60Hz, 30W (no HDD) |
| Size |
445 × 436 × 90 mm |
| Certification |
CE & FCC & KCC & WEEE, RoHS |
