Image Sensor |
1/2.7” Progressive Scan CMOS |
Maximum resolution |
2688 × 1520 |
Minimum illumination |
Day : 0.007 Lux @ (F1.2, AGC ON) |
Night : 0.012 Lux @ (F1.6, AGC ON) |
Shutter speed |
1/3s ~ 1/100,000s |
Focus |
Fixed |
LENS |
2.8 mm / 4 mm / 6 mm / 8 mm |
Aperture |
F1.6 |
Angle adjustment |
Pan : 0° ~ 360°, tilt : 0° ~ 75°, rotate : 0° ~ 360° |
Angle of view |
2.8 mm |
Horizontal : 104°, Vertical : 58°, Diagonal : 124° |
4 mm |
Horizontal : 83°, Vertical : 44°, Diagonal :99° |
6 mm |
Horizontal : 51, Vertical : 28°, Diagonal : 58° |
8 mm |
Horizontal : 39°, Vertical : 21°, Diagonal : 45° |
DNR |
3D DNR |
WDR |
120 dB |
Day/Night |
IR cut filter |
IR distance |
2 LED |
up to 50 m |
4 LED |
up to 80 m |
IR wavelength |
850 nm |
Image |
Mainstream |
50Hz : 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720) |
60Hz : 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720) |
Substream |
50Hz : 25 fps (704 × 576, 640 × 480, 352 × 288) |
60Hz : 30 fps (704 × 480, 640 × 480, 352 × 240) |
Third Stream |
50Hz : 25fps (1280 × 720, 640 × 480, 640 × 360, 320 × 240) |
60Hz : 30fps (1280 × 720, 640 × 480, 640 × 360, 320 × 240) |
Image improvement |
BLC/3D DNR |
Day/Night Selection |
Day/Night/Auto/Schedule |
Video |
Mainstream |
H.265/H.264 |
Substream |
H.265/H.264/MJPEG |
Third Stream |
H.265/H.264 |
Bitrate |
32 Kbps ~ 16 Mbps/span> |
Audio |
Noise filter |
Yes |
Speed |
8kHz/16kHz/span> |
Compression |
G.711/G.722.1/G.726/MP2L2/PCM |
Bitrate |
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-160Kbps(MP2L2)/span> |
Smart Function |
Line crossing detection, intrusion detection, zone entry/breakaway detection |
