Image sensor : 1/2.9" 2.1MP Progressive Sensor
Scan system : Progressive
Resolution : FHD / HD / D1 / CIF
Frame rate : 30fps@1080p
Compress Format : H.265 / H.264 / H.265+ / H.264+
Bit rate : H.265: 32k~8192kbps / H.264: 32k~8192kbps
Bit rate control : CBR / VBR
Network interface : RJ-45 (10/100Bast-T)
Protocol : HTTP/TCP/RTSP/SMTP/FTP/DHCP/DNS/DDNS / IPv4/NTP/802.1x
Onvif : ONVIF 2.4 (Profile S/T)
Streaming : Unicast
Max. User access : 8 users
Web viewer : IE / Edge / Chrome / FireFox / Opera
S/N Ratio: 60dB or More (AGC Off)
IR Led : SMD LED 42μ x 2pcs (Smart IR)
Day & Night : AUTO / COLOR / B/W
Min.Illumincation : 0Lux (LED On)
Lens : 3.6mm Fixed Lens
Backlight compensation : BLC
Motion detection : 22x18 area
Digital Zoom : Linear Digital Zoom
Screen change : Flip / Mirror / Hallway view
Privacy masking : OFF / ON (4area)
Operating temperature : -20~60˚C
Humidity: 95% RH
Input voltage : DC 12V / PoE (802.3af)
Dimension(mm) : Ø109 x93(H)mm
Weight : Aprrox. 0.6Kgs
